Layers: 8 ~ 22 layers
Minimum line width/spacing: 8/8 μm
Board thickness: 0.3 mm ~ 2.2 mm
BU Laser/Pad: 50/75 μm
Minimum uBump pitch: 110 μm
Surface treatment: IT/ENEPIG+uBall
Used in computer CPUs, GPUs, MCUs, ASIC specialized chips, etc.
